HC-Cargo Laturi
HC-Cargo Laturi
Tuotenro.: F032116591

HC-Cargo Laturi

Tekniset tiedot:

Jännite: 14 V, Amp: 150, Asennuskiinnikkeen etäisyys: 83,50, Renkotädin ø: 55,00

Kuvaus

Nimellisäädin: 14
Ampere: 150
Hihnan kiinnityspituus: 41.50
Leveys/kannattimen varren etäisyys: 14.00
Asennusjalan etäisyys: 83.50
Kiinnityskohdan reikä: 10.50
Venytysvarren säädettävän kiinnityspultin positio: 56
Venytysvarren säädettävän kiinnityspultin reikä 1: 10.50
Holkin halkaisija: 55.00
URat/holkki: 7
Säde: 94.00
Säde 2: 95.50
B+: M8
Sijainti/B+: väh. aika: 22
Pistokkeen nro.: PL174
Kokonaispituus mm: 184.00
Terminaalityyppi: COM
ID-koodi: 24
Viestintä: LIN
Holkki: SP/FW
Tuuliyksikkö: IF
Säädintyyppi: IR
Huomautukset: Tämä generaattoriin on COM-terminaali säädinssä. On suositeltavaa käyttää OEM-numeroa sopivuuden tarkistamiseen ennen tilausta.

Tiedostot

Määrittely

B+ M8
Communication LIN
Mount. bracket dist. 83.50
Belt. adj. bracket hole 1 10.50
Belt. adj. brackethole pos. 56
Plug no. PL174
Bracket hole 10.50
Position/B+ in min. 22
Pulley SP/FW
Pulley dia. 55.00
Pulley dist. 41.50
Radius 94.00
Radius 2 95.50
Regulator type IR
Remarks This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.
Fan IF
Grooves/pulley 7
ID Code 24
Terminal type COM
Voltage 14
Total length 184.00 mm
Width/holder arm 14.00
Amp 150

  • OEM
    F000BL07CE, F000BL07CF, F032116591, 1986A01521, 5802217842

  • Konkurrentreferens
    A0826S, CAL10024, LRA04476, 28-8585, 505.906.150, 443396, 444279, 554856RIB, 12090984, 32446540

  • NormaliseratArtNr
    a0826s, cal10024, f000bl07ce, f000bl07cf, f032116591, lra04476, 1986a01521, 288585, 443396, 444279, 554856rib, 12090984, 32446540, 505906150, 5802217842

  • Passar modeller
    Iveco Model: Daily Model series: 33 S 13 Size of motor: 2.3 Brand of engine: F1AFL411B Body: Platform / Chassis From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
    Iveco Model: Daily Model series: 33S11, 35S11, 35C11 Size of motor: 2.3 Brand of engine: F1AFL411A Body: Twin Cab From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
    Iveco Model: Daily Model series: 33S15, 35S15, 35C15 Size of motor: 2.3 Brand of engine: F1AFL411C Body: Platform / Chassis From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
    Iveco Model: Daily Model series: 33S15, 35S15, 35C15 Size of motor: 2.3 Brand of engine: F1AFL411C Body: Twin Cab From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
    Iveco Model: Daily Model series: 35 C 11 Type of engine: Diesel Size of motor: 2.3 Brand of engine: F1AFL411A Body: Platform / Chassis From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
    Iveco Model: Daily VI Model series: 33 S 11 Type of engine: Diesel Size of motor: 2.3 Brand of engine: F1AE3481A Body: Platform / Chassis From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
    Iveco Model: Daily VI Model series: 33 S 11 Type of engine: Diesel Size of motor: 2.3 Brand of engine: F1AE3481B Body: Platform / Chassis From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
    Iveco Model: Daily VI Model series: 33 S 11 Type of engine: Diesel Size of motor: 2.3 Brand of engine: F1AE3481C Body: Platform / Chassis From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
    Iveco Model: Daily VI Model series: 33-120, 35-120 Type of engine: Diesel Size of motor: 2.3 Body: Platform / Chassis From date: 01-04-2016 Fuel: Diesel Approved: Yes
    Iveco Model: Daily VI Model series: 33-120, 35-120 Type of engine: Diesel Size of motor: 2.3 Body: Twin Cab From date: 01-04-2016 Fuel: Diesel Approved: Yes
    Iveco Model: Daily VI Model series: 33-140, 35-140 Type of engine: Diesel Size of motor: 2.3 Body: Platform / Chassis From date: 01-04-2016 Fuel: Diesel Approved: Yes
    Iveco Model: Daily VI Model series: 33-140, 35-140 Type of engine: Diesel Size of motor: 2.3 Body: Twin Cab From date: 01-04-2016 Fuel: Diesel Approved: Yes
    Iveco Model: Daily VI Model series: 33-160, 35-160 Type of engine: Diesel Size of motor: 2.3 Body: Platform / Chassis From date: 01-04-2016 Fuel: Diesel Approved: Yes
    Iveco Model: Daily VI Model series: 33-160, 35-160 Type of engine: Diesel Size of motor: 2.3 Body: Twin Cab From date: 01-04-2016 Fuel: Diesel Approved: Yes
    Iveco Model: Daily VI Model series: 33S11, 35S11, 35C11 Type of engine: Diesel Size of motor: 2.3 Brand of engine: F1AE3481A Body: Twin Cab From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
    Iveco Model: Daily VI Model series: 33S11, 35S11, 35C11 Type of engine: Diesel Size of motor: 2.3 Brand of engine: F1AE3481C Body: Twin Cab From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
    Iveco Model: Daily VI Model series: 33S11, 35S11, 35C11 Type of engine: Diesel Size of motor: 2.3 Brand of engine: F1AFL411B Body: Twin Cab From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
    1 / 4
  • Kuvaus
    Nimellisäädin: 14
    Ampere: 150
    Hihnan kiinnityspituus: 41.50
    Leveys/kannattimen varren etäisyys: 14.00
    Asennusjalan etäisyys: 83.50
    Kiinnityskohdan reikä: 10.50
    Venytysvarren säädettävän kiinnityspultin positio: 56
    Venytysvarren säädettävän kiinnityspultin reikä 1: 10.50
    Holkin halkaisija: 55.00
    URat/holkki: 7
    Säde: 94.00
    Säde 2: 95.50
    B+: M8
    Sijainti/B+: väh. aika: 22
    Pistokkeen nro.: PL174
    Kokonaispituus mm: 184.00
    Terminaalityyppi: COM
    ID-koodi: 24
    Viestintä: LIN
    Holkki: SP/FW
    Tuuliyksikkö: IF
    Säädintyyppi: IR
    Huomautukset: Tämä generaattoriin on COM-terminaali säädinssä. On suositeltavaa käyttää OEM-numeroa sopivuuden tarkistamiseen ennen tilausta.

    Tiedostot

  • Määrittely
    B+ M8
    Communication LIN
    Mount. bracket dist. 83.50
    Belt. adj. bracket hole 1 10.50
    Belt. adj. brackethole pos. 56
    Plug no. PL174
    Bracket hole 10.50
    Position/B+ in min. 22
    Pulley SP/FW
    Pulley dia. 55.00
    Pulley dist. 41.50
    Radius 94.00
    Radius 2 95.50
    Regulator type IR
    Remarks This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.
    Fan IF
    Grooves/pulley 7
    ID Code 24
    Terminal type COM
    Voltage 14
    Total length 184.00 mm
    Width/holder arm 14.00
    Amp 150
  • Nämä ajoneuvot sopivat

    • OEM
      F000BL07CE, F000BL07CF, F032116591, 1986A01521, 5802217842

    • Konkurrentreferens
      A0826S, CAL10024, LRA04476, 28-8585, 505.906.150, 443396, 444279, 554856RIB, 12090984, 32446540

    • NormaliseratArtNr
      a0826s, cal10024, f000bl07ce, f000bl07cf, f032116591, lra04476, 1986a01521, 288585, 443396, 444279, 554856rib, 12090984, 32446540, 505906150, 5802217842

    • Passar modeller
      Iveco Model: Daily Model series: 33 S 13 Size of motor: 2.3 Brand of engine: F1AFL411B Body: Platform / Chassis From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
      Iveco Model: Daily Model series: 33S11, 35S11, 35C11 Size of motor: 2.3 Brand of engine: F1AFL411A Body: Twin Cab From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
      Iveco Model: Daily Model series: 33S15, 35S15, 35C15 Size of motor: 2.3 Brand of engine: F1AFL411C Body: Platform / Chassis From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
      Iveco Model: Daily Model series: 33S15, 35S15, 35C15 Size of motor: 2.3 Brand of engine: F1AFL411C Body: Twin Cab From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
      Iveco Model: Daily Model series: 35 C 11 Type of engine: Diesel Size of motor: 2.3 Brand of engine: F1AFL411A Body: Platform / Chassis From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
      Iveco Model: Daily VI Model series: 33 S 11 Type of engine: Diesel Size of motor: 2.3 Brand of engine: F1AE3481A Body: Platform / Chassis From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
      Iveco Model: Daily VI Model series: 33 S 11 Type of engine: Diesel Size of motor: 2.3 Brand of engine: F1AE3481B Body: Platform / Chassis From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
      Iveco Model: Daily VI Model series: 33 S 11 Type of engine: Diesel Size of motor: 2.3 Brand of engine: F1AE3481C Body: Platform / Chassis From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
      Iveco Model: Daily VI Model series: 33-120, 35-120 Type of engine: Diesel Size of motor: 2.3 Body: Platform / Chassis From date: 01-04-2016 Fuel: Diesel Approved: Yes
      Iveco Model: Daily VI Model series: 33-120, 35-120 Type of engine: Diesel Size of motor: 2.3 Body: Twin Cab From date: 01-04-2016 Fuel: Diesel Approved: Yes
      Iveco Model: Daily VI Model series: 33-140, 35-140 Type of engine: Diesel Size of motor: 2.3 Body: Platform / Chassis From date: 01-04-2016 Fuel: Diesel Approved: Yes
      Iveco Model: Daily VI Model series: 33-140, 35-140 Type of engine: Diesel Size of motor: 2.3 Body: Twin Cab From date: 01-04-2016 Fuel: Diesel Approved: Yes
      Iveco Model: Daily VI Model series: 33-160, 35-160 Type of engine: Diesel Size of motor: 2.3 Body: Platform / Chassis From date: 01-04-2016 Fuel: Diesel Approved: Yes
      Iveco Model: Daily VI Model series: 33-160, 35-160 Type of engine: Diesel Size of motor: 2.3 Body: Twin Cab From date: 01-04-2016 Fuel: Diesel Approved: Yes
      Iveco Model: Daily VI Model series: 33S11, 35S11, 35C11 Type of engine: Diesel Size of motor: 2.3 Brand of engine: F1AE3481A Body: Twin Cab From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
      Iveco Model: Daily VI Model series: 33S11, 35S11, 35C11 Type of engine: Diesel Size of motor: 2.3 Brand of engine: F1AE3481C Body: Twin Cab From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
      Iveco Model: Daily VI Model series: 33S11, 35S11, 35C11 Type of engine: Diesel Size of motor: 2.3 Brand of engine: F1AFL411B Body: Twin Cab From date: 01-03-2014 To date: 01-04-2016 Fuel: Diesel Approved: Yes
